UCT Beacon Bluetooth BLE iBeacon
Indoor Positioning Solution
- Bluetooth BLE iBeacon (BCN02) based on Diglog IC and supports Bluetooth 5.1 protocol.
- Designed for indoor positioning solutions, works with LoRaWAN trackers.
- Low power consumption with 1200mAh battery for 4~5 years of operation.
- 500ms default broadcast interval, configurable via mobile phone.
- Valid for outdoor use, weather-proof design, and easy installation.
Description
The BCN02 is a Bluetooth BLE iBeacon designed for indoor positioning solution. BCN02 is base on Diglog IC and support Bluetooth 5.1 protocol. BCN02 is low power consumption and with 1200mAh battery. With a 500ms broadcast interval, BCN02 can works for 4~5 years.
BCN02 is designed for the use together with Dragino TrackerD to provide LoRaWAN Indoor Position Solution. There are many BCN02s placed in different location and keep broadcasting their UUID via Bluetooth. User brings TrackerD LoRaWAN BLE tracker, the TrackerD keep scanning the UUID and choose the highest signal UUID to uplink via LoRaWAN. So the IoT server will know where the TrackerD is.
BCN02 is power off when shipping via airline. User need to rotate to open it and plug in the power connector to power on it.
Technical Specifications
| Battery | 1200mAh |
|---|---|
| Battery Life | 4~5 years (Default 500ms Interval) |
| Protocol | Bluetooth 5.1 |
| Distance | 100 meters in open area |
| RF Power | -19.5 ~ 2.5dBm (default 2.5dBm) |
| Operating Temperature | -30 ~ 60 °C |
| Sleep Current | 0.27uA |
| Broadcasting Current | 16uA |
Key Features
Bluetooth 5.1
Supports latest Bluetooth 5.1 protocol for efficient communication.
Long Battery Life
4-5 years operation with 1200mAh battery.
Indoor Positioning
Ideal for LoRaWAN indoor positioning solutions.
Weather Proof
Valid for outdoor use, withstands harsh conditions.
Easy Configuration
Configurable via mobile phone app.
Documents
Product manuals, datasheets, or PDFs are here...
